Description of Gabion Basket
Gabion Basket (Boxes) are made of hexagonal Galvanized/PVC/Zinc-Al double-twised mild steel wire mesh.
Gabion baskets can be supplied in various lengths, widths and heights. In order to strengthen the baskets, all the edges of the structure shall be selvedged thicker wire diameter.
These Gabion boxes are filled with natural stones at the project site to form flexible, permeable, monolithic structures such as Retaining walls, sea walls, channel lining, revetments, and wires for erosion control projects.
Specifications of Gabion Basket
| Surface Treatment | Mesh Size | Mesh Wire(mm) | Selvedge Wire(mm) | Lacing Wire(mm) |
Heavy Hot dipped
Galvanized or
Golfan galvanized
and PVC coating | 60*80 | 2.0mm/3.0mm
2.2mm/3.2mm | 2.8mm/3.8mm
3.0mm/4.0mm | 1.8mm/2.8mm
2.0mm/3.0mm |
80*100
80*120 | 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm | 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm |
2.2mm/3.2mm |
100*120
100*150 | 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm | 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm |
2.2mm/3.2mm |
120*150 | 2.2mm/3.2mm
2.5mm/3.5mm
2.7mm/3.7mm | 3.0mm/4.0mm
3.2mm/4.2mm
3.4mm/4.4mm |
2.2mm/3.2 |
Features of Gabion Basket
(1) It is convenient to use, and can be used only by tiling the net surface into wall surfaces and building cement;
(2) the construction is simple and does not need special technology;
(3) Strong ability to resist natural damage, corrosion and adverse weather effects;
(4) can withstand large-scale deformation without collapsing. It plays a role in fixing heat preservation and heat insulation.
(5) The excellent technological foundation ensures the uniformity of coating thickness and has stronger corrosion resistance,
(6) Save transportation costs. It can be shrunk into small rolls and wrapped in moisture-proof paper, occupying little space.
Applications of Gabion Basket
Gabion box can be used for making slope, rock,slope vegetation,rail-way or highway guardrail mesh stable. Also it can be made into basket, mesh mat for protecting dam which easily ruined by flood and lead to property losses. Therefore, application of gabion basket is the best solution of solving the problem that give dams lasting protection.
Welded gabion box is manufactured from cold steel wire with high tensile strength. It is electrically welded together then hot dipped galvanized or PVC coated, ensuring a longer life. There are galvanized welded gabions and PVC welded gabions. Welded Gabion box is designed on the principle of mass earth retaining wall. The strength of the wire mesh helps to stand the forces generated by the retained soil.
Company Profile
1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.
3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.
4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.
5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.
6. Is it sample available?
Yes, small pieces of sample are available in our company.
